PCB design & layout, built for manufacturing.

High-speed, HDI and complex multilayer layouts from a design team that thinks about fabrication from the very first trace.

Our advantages

Why design with Vayu

Proven HDI expertise

Our technology partner brings decades of experience in HDI, semiconductor test boards and complex multilayer design.

DFM-driven layout

Every layout is checked with industry-standard DFM/DFA tools for accuracy, yield and reliability.

Multi-platform

We work natively in the leading EDA tools, so your files fit straight into your existing flow.

Your IP, protected

All projects run under strict NDAs with end-to-end protection of schematics and design data.

Design procedure

How a layout project runs

Requirements

Netlist, schematic, BOM and mechanical constraints.

Stack-up & Rules

Layer stack, impedance and design-rule planning.

Placement & Routing

Component placement, high-speed and HDI routing.

DFM / SI Review

Signal-integrity, EMI and manufacturability checks.

Release

Gerbers, drill files, fab & assembly drawings.

Capabilities

PCB layout capabilities

Complex, dense boards are our everyday work.

ItemCapability
Max layer count40
Min trace / space (HDI)3 mil / 3 mil
Max pin count60,000
Min BGA pin pitch0.3 mm
Max BGA pin count2,500
Max signal rate12 Gbps
Min aperture3 mil
Beyond the table

Advanced layout

We specialise in the details that make dense, fast boards work first time:

  • Blind / buried vias, via-in-pad and embedded capacitors & resistors
  • High-speed and high-frequency layout
  • Analog, digital and mixed-signal partitioning
  • EMI reduction and EMC optimisation
  • Impedance-controlled stack-ups matched to fabrication

EDA platforms

Siemens XpeditionCadence Allegro / OrCADAltium DesignerZuken CR-8000Valor DFM / DFA
Circuit design
Getting started

What to send us

The more we know up front, the faster we can quote and start layout.

  • Netlist (PADS / OrCAD 7.0 and above) and schematic
  • Complete bill of materials and component parameters
  • Critical voltages and high-speed / sensitive nets
  • Board size and mechanical specifications
  • Placement requirements, special pads and drill sizes
  • Silkscreen legend, part / model / revision codes
  • Approval and testing requirements

Need a layout done right the first time?

Tell us about your board and timeline — we’ll respond with an approach and a quotation.
